| Product Features |
Lantern Post top light is designed to meet the needs for outdoor lighting, like square , garden ,
pathway ,places where need energy saving and high color rendering index lighting.
•130lm/w or 150lm/w
•Photocell is available
•Surge protector (Optional): 10KV
•Dimmable
(Optional): 0-10V
•Mounting : for diameter 60mm or 75mm tenons
•Mounting : for diameter 60mm or
75mm tenons
•Ip65 for outdoor lighting
| Technical Specifications |
| Item No. | AL-70W |
| Rated Power | 70W |
| Input Voltage | 100-277Vac or 100-347Vac or 200-480Vac |
| Power Factor | PF>0.95 |
| LED Luminous Efficiency | 130lm/w or 150lm/w |
| Beam angle | Type 4 (80*150 degree) |
| Luminous Flux(125lm/w) | 9,100lm |
| Luminous Flux(150lm/w) | 10,500lm |
| Color Temperature | 2200K, 2700K, 3000k, 4000k, 4500k, 5000k, 5700k, 6500k,Amber, Red, Green, Blue. |
| Color Rendering Index(CRI) | Ra＞83 |
| LED Emitter Life | >50,000 hours |
| Replacement | 225-275w MH,HPS |
| Dimension | Φ400*800mm |
| Warranty | 5 years factory warranty |
| Dimension |
| Why US ? |
From our 10 years experience, many clients has problem with these corn lights in the current market, most failures can be bolt down to heat problem or driver problem. However, we are making the change to improve. It's credit!
| Applications |
•Application: garden, pathway, yard, outdoor area, road, pole lighting
| The relevant product parameters |
| Item No. | Watts | Power Factor | Luminous Flux(150lm/w) | Replacement | Diameter | CRI |
| AL-20W | 20W | PF>0.95 | 3,000lm | 40-60w CFL | 400*400*800mm | Ra>83 |
| AL-30W | 30W | PF>0.95 | 4,500lm | 75-105w MH, HPS | 400*400*800mm | Ra>83 |
| AL-70W | 70W | PF>0.95 | 10,500lm | 225-275w MH, HPS | 400*400*800mm | Ra>83 |
| AL-100W | 100W | PF>0.95 | 15,000lm | 250-300w MH, HPS | 400*400*800mm | Ra>83 |
